Accurate Digital Technology
|
JENO Engine (Jitter Elimination and Noise-shaping Optimization), Load Adaptive Phase Calibration (w/o Calibration function), Space Tune™, Twin Power Supply Circuit System, Re-master
|
|
Noiseless Signal Technology
|
Twin Power Supply Circuit System, Optimally Activated Circuit System, CD High-Res Re-master
|
|
Emotive Acoustic Technology
|
Acoustic Lens and Louver, Dual bass reflex port
|
|
Output Power
|
Front speaker: 30 W + 30 W (1 kHz, T.H.D. 1.0 %, 6Ω, 20 kHz LPF), Subwoofer : 40 W (70Hz, T.H.D. 1.0 %, 4Ω, 20 kHz LPF)
|
|
Speaker Unit
|
Woofer : 8 cm Cone Type x2 / Tweeter: 2 cm Dome Type x 2 / Subwoofer: 12 cm Cone Type
|
|
Analogue Input Terminal
|
AUX IN x1 (φ3.5mm) (1/8 inch)
|
|
Digital Input Terminal
|
Optical Digital x1, USB-A
|
|
|
|
|
|
Audio CD, CD-R/CD-RW (CD-DA, Discs recorded and finalized on recording devices)
|
|
|
|
USB-A - Support Codec (WAV)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
USB-A - Support Codec (FLAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
USB-A - Support Codec (DSD)
|
Yes (2.8 MHz, 5.6 MHz, 11.2MHz)
|
USB-A - Support Codec (AIFF)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
USB-A - Support Codec (ALAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
USB-A - Support Codec (AAC)
|
Yes (32, 44.1, 48, 88.2, 96 kHz / 16-320 kbps)
|
|
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
|
Yes (2.8 MHz, 5.6 MHz, 11.2MHz)
|
|
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
|
Yes (32, 44.1, 48, 88.2, 96 kHz / 16-320 kbps)
|
|
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
|
LAN (100 Base-TX/10 Base-T)
|
|
|
IEEE 802.11 a/b/g/n/ac, 2.4 GHz / 5 GHz Band
|
|
|
|
Works with Google Assistant
|
|
|
|
|
Bluetooth® (Support codec)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
450 x 143 x 280 mm, 17-23/32 x 5-5/8 x 11-1/32 inch
|
|
|
Approx. 8.0kg (Approx. 17.6 lbs.)
|
|
|
Remote Control, AC Cord, DAB Indoor Antenna, Batteries for Remote Control
|
