Rotel DX-5 Stereo Integrated Amplifier Key Features:
-
Class AB amplification with 33W into 4 ohms (25W into 8 ohms) – Delivers clean, dynamic sound with the headroom needed for demanding speakers or headphones.
-
Custom-wound high-current toroidal transformer – Ensures stable power delivery and low noise for enhanced audio fidelity.
-
ESS ES9039Q2M premium DAC – Reproduces music with stunning detail, clarity, and expansive imaging across digital sources.
-
PC-USB input supporting 32-bit/384kHz PCM and DSD 4x – Enables ultra-high-resolution playback from your computer or streamer.
-
Coaxial and optical digital inputs (24-bit/192kHz) – Supports versatile digital source connectivity with excellent signal integrity.
-
aptX™ HD and AAC Bluetooth – Offers high-quality wireless streaming with better-than-CD sound quality and broad device compatibility.
-
HDMI ARC input – Simplifies integration with TVs for immersive two-channel audio from video sources.
Product Description:
The Rotel DX-5 is a compact yet powerful personal audio integrated amplifier designed for audiophiles, music enthusiasts, and home entertainment users alike. Combining modern technology with flexible connectivity options, it features Rotel’s renowned Class AB amplification, delivering 33 watts into 4 ohms (25 watts into 8 ohms). Housed in a sleek, industrial-style chassis, the DX-5 offers high-performance sound in a space-saving form that complements any setup.
Engineered with care.
The Rotel DX-5 is a high-performance personal audio integrated amplifier that merges refined industrial design with exceptional engineering. At its core is a precision Class AB amplifier, driven by a custom-wound high-current toroidal transformer, delivering 33 watts per channel into 4 ohms (25 watts into 8 ohms).
Equipped with the premium ESS ES9039Q2M DAC, the DX-5 offers remarkable clarity and musical detail across a wide soundstage. It supports an array of modern and legacy inputs, including PC-USB (32-bit/384kHz PCM, DSD 4x), coaxial and optical (24-bit/192kHz), aptX™ HD and AAC Bluetooth, RCA analog, HDMI ARC, and a dedicated subwoofer output.
Designed for both convenience and performance, the DX-5 includes a full-color TFT display, a 1/4” (6.35mm) headphone output, and an easy-to-use remote control—making it an ideal centerpiece for personal listening setups and home entertainment systems.
Specifications:
|
Front Panel Height
|
70 mm (2 3/4")
|
|
Power Requirements
|
120 V, 60 Hz
|
|
Power Consumption
|
80 W
|
|
Standby Power Consumption
|
<0.5 W
|
|
Net Weight
|
4.1 kg (9.1 lbs.)
|
|
BTU
|
241 BTU/h
|
|
Power Output (FTC)
|
25 W / ch
|
|
Maximum Power Output (Non FTC)
|
33 W / ch (1k Hz, 4 Ω)
|
|
Continuous Power Output (Non FTC)
|
25 W / ch (1k Hz, 8 Ω)
|
|
Total Harmonic Distortion
|
< 0.03%
|
|
Frequency Response
|
10 Hz – 100k Hz (0 ± 0.19 dB)
|
|
Damping Factor (20 Hz – 20k Hz, 8 Ω)
|
140
|
|
Input Sensitivity / Impedance
|
680 mV / 100k Ω
|
|
Input Overload
|
4.2 V
|
|
S/N Ratio (IHF "A" Weighted)
|
>100 dB
|
Dimensions and Weight:
Overall -
|
Dimensions (W × H × D)
|
215 x 76 x 251 mm
|
|
Dimensions (W × H × D)
|
8 1/2 x 3 x 10"
|
Product Weight - 4.1 kg (9.1 lbs.)
