Rotel A8 Stereo Integrated Amplifier Key Features:
-
40 Watts of Class AB Power – Delivers dynamic, detailed sound into 4-ohm speakers from a compact chassis.
-
Custom Toroidal Transformer – In-house engineered for smooth, high-current power delivery and efficiency.
-
Analog Versatility – Includes three RCA inputs and a Moving Magnet phono stage for vinyl playback.
-
Front-Panel Tone and LED Controls – Adjustable Bass, Treble, and LED volume indicators personalize your setup.
-
Convenient Headphone and Remote Access – 1/8" headphone jack and IR remote for easy, flexible control.
Product Description:
The A8 Integrated Amplifier strikes the ideal balance of power, efficiency, and compact design, offering 40 watts per channel of Class AB amplification into 4 ohms. At its core is a high-current Rotel-built toroidal transformer, ensuring smooth, reliable performance across a variety of loudspeakers.
Three RCA analog inputs and a dedicated Moving Magnet phono stage make it easy to connect a range of sources, including turntables, for a warm and engaging vinyl listening experience. Designed with value and simplicity in mind, the A8 is a perfect entry point for those looking to elevate their audio system without compromise.
Engineered with care.
The Rotel A8 Integrated Amplifier strikes a refined balance of power, efficiency, and compact design—crafted for discerning music lovers seeking exceptional performance and value.
At its heart lies a custom-built, high-current toroidal transformer engineered in-house by Rotel, delivering 40 watts per channel of robust Class A/B power into 4-ohm loads. High-efficiency output transistors provide tight bass control and dynamic accuracy, maintaining composure and precision across all listening levels.
The A8 supports a variety of analog sources with three line-level RCA inputs and a dedicated Moving Magnet Phono stage for vinyl playback. A front-panel 1/8” headphone output offers convenient access for private listening.
An included IR remote allows intuitive control over volume and input selection from across the room and includes transport functions for compatible Rotel CD players.
Users can personalize the visual experience with selectable LED volume indicators in Red, Green, Blue, or Purple—adjustable to suit any mood or décor. Front-panel tone controls for Bass, Treble, and Balance offer further customization for a truly tailored listening experience.
Rear-panel 5-way speaker binding posts provide flexible, secure speaker connectivity.
Available in elegant black or silver finishes, the Rotel A8 delivers sophisticated sound, intuitive control, and sleek aesthetics—perfectly suited for any music environment.
Specifications:
|
Front Panel Height
|
60 mm (2 3/8”)
|
|
Power Requirements
|
120 V, 60 Hz
|
|
Power Consumption
|
110 W
|
|
Standby Power Consumption
|
<0.5 W
|
|
BTU Rating (4 Ω, 1/8th power)
|
340 BTU/h
|
|
Power Output
|
30 W/Ch (8 Ω)
40 W/Ch (4 Ω)
|
|
Total Harmonic Distortion (THD)
|
<0.03%
|
|
Frequency Response
|
Line Level Inputs: 10 Hz - 100k Hz, -0.5 dB, +0 dB
Phono Input: 20 Hz - 20k Hz, -0.5 dB, +0 dB
|
|
S/N Ratio (IHF "A" Weighted)
|
Line Level Inputs: 90 dB (Max Volume)
Line Level Inputs: 102 dB (Min Volume)
Phono Input: 80 dB
|
Dimensions and Weight:
Overall -
|
Dimensions (W × H × D)
|
430 × 73 × 347 mm
|
|
Dimensions (W × H × D)
|
17” × 2 7/8” × 13 5/8”
|
Product Weight - 5.8 kg (12.8 lbs)
