Michi X5 Series 2 Integrated Amplifier Key Features:
- 600 watts of Class AB output power – Delivers robust, effortless drive for even the most demanding loudspeakers
- ESS SABRE 8-channel DAC – Ensures exceptional digital-to-analog conversion with precision, detail, and musicality
- Comprehensive input support – Handles Analog, Digital, XLR, PC-USB, aptX™ HD Bluetooth, and Phono (MM/MC) sources for total system versatility
- Built-in Moving Magnet and Moving Coil phono stage – Enables high-performance vinyl playback without the need for external components
- Integrated amplifier design – Combines preamp and power amp in one chassis for space efficiency and optimized signal path
- aptX™ HD Bluetooth streaming – Offers high-resolution wireless audio for convenient, cable-free listening
Product Description:
The Michi X5 Series 2 Integrated Amplifier delivers commanding performance and uncompromising precision, offering up to 600 watts of Class AB output power per channel. Its robust linear power supply features dual, in-house manufactured toroidal transformers—fully shielded and optimized for low noise—ensuring stable current delivery and dynamic headroom.
At the heart of its digital performance lies an ESS SABRE 8-channel DAC, engineered to extract extraordinary detail and tonal accuracy from any source. The X5 Series 2 accommodates a full suite of inputs, including analog RCA and balanced XLR, a Moving Magnet and Moving Coil phono stage, Bluetooth with aptX™ HD, as well as coaxial and optical digital inputs. Its PC-USB input supports high-resolution formats up to 32-bit/384kHz PCM, Quad DSD (11.2MHz), and full MQA decoding at up to 24-bit/384kHz.
Built to satisfy the demands of music lovers, audiophiles, and professionals alike, the X5 Series 2 combines refined industrial design with meticulous craftsmanship. Its elegant appearance is matched by exceptional build quality, making it a powerful and sophisticated centerpiece for any high-end audio system.
Specifications:
|
Front Panel Height
|
177 mm (7")
|
|
Power Requirements
|
120V, 60Hz
|
|
Power Consumption
|
850W
|
|
Standby Power Consumption
|
<0.5W
|
|
BTU Rating
|
2194 BTU/h
|
|
Continuous Power Output
|
600W/Ch (4Ω)
350W/Ch (8Ω)
|
|
Total Harmonic Distortion (THD)
|
<0.009%
|
|
Frequency Response
|
Line Level Inputs: 10Hz - 100kHz (+0 dB, -0.6 dB)
Digital Inputs: 20Hz - 20kHz (0 ± 0.4 dB)
Phono Input: 20Hz - 20kHz (+0 dB, -0.2 dB)
|
|
S/N Ratio (IHF "A" Weighted)
|
Line Level Inputs: 102dB
Digital Inputs: 102dB
Phono Input: 80dB
|
|
Intermodulation Distortion (60Hz:7kHz, 4:1)
|
<0.03%
|
|
Damping Factor (20 Hz - 20kHz, 8 ohms)
|
350
|
|
Channel Separation
|
>65dB
|
|
Input Sensitivity
|
Line Level (RCA): 380mV
Line Level (XLR): 580mV
Phono (MM): 5.7mV
Phono (MC): 570 uV
|
|
Input Impedance
|
Line Level (RCA): 100kΩ
Line Level (XLR): 100kΩ
Digital Inputs: 75Ω
Phono (MM): 47kΩ
Phono (MC): 100Ω
|
|
Input Overload
|
Line Level (RCA): 12.5V
Line Level (XLR): 12.5V
Phono (MM): 197mV
Phono (MC): 19mV
|
|
Preout Level
|
1V
|
|
Output Impedance
|
470Ω
|
|
Tone Controls
|
±10dB at 100Hz / 10kHz
|
|
Coax/Optical Digital Input Signals
|
SPDIF LPCM (Up to 24-bit/192kHz)
|
|
PC-USB
|
USB Audio Class 1: Up to 24-bit/96kHz
USB Audio Class 2: Up to 32-bit/384kHz
|
|
MQA, DSD and DoP Support
|
Yes
|
|
Roon Tested Support
|
Yes
|
Dimensions and Weight:
Overall - 19 x 7 5/8 x 17 3/4” (W x H x D)
Product Weight - 96.56 lbs net
