Marchand Model XM26 Vacuum Tube Electronic Crossover


Current stock: 0

Product: Marchand Model XM26 Vacuum Tube Electronic Crossover

Product SKU: 11836

Voltage: 120V

Cosmetic Description: 8/10 Excellent condition with minimal visible cosmetic wear including light scratching on the housing. This item shows some wear consistent with its age but is still presentable and sounds wonderful.

What is Included: Crossover, 8 12AX7 tubes, Power cable

Functional Notes: Operational condition of this item is excellent, fully tested and no issues found.

Age: Unknown

# of Owners: Unknown

Tobacco Exposure: No

Service History: None

MSRP: $2000

Other Notes: "The XM26 Electronic Crossover Network is a fourth- order constant-voltage crossover design that provides both low-pass and high-pass outputs. The slope of each output is 24 dB/octave and, because of the fourth-order design, the high-pass and low-pass outputs of the crossover are always in phase with each other. The XM26 uses 4 12AX7 tubes in each of the two channels. It has a solid state regulated power supply for the filament voltage. Power is provided with a heavy duty toroidal power transformer. The crossover frequency of XM26 Electronic Crossover Network can easily be set by replacing a frequency module. A total of four frequency modules set the crossover frequency for left and right, low and high pass filters. Each frequency module has the capacitors and resistors that set the crossover frequency and slope for that channel. Normal slope is 24 dB/oct, 4th order, constant voltage (Linkwitz-Riley), but modules for first, second and third order slopes are also available. The XM26 front panel has 4 calibrated level controls using stepped attenuators, one for each low pass and high pass, for left and right channel. A sum switch allows the low pass channel to be summed. This is useful when using the XM26 with a common subwoofer."

Model No. XM26-AA
