About ATC EL50 Anniversary Floorstanding Speakers; European Walnut Pair
ATC EL50 Anniversary Floorstanding Speakers Key Features:
- Elliptical curved cabinet for low diffraction
- ATC 9”/234mm 'SL' bass driver
- ATC 3”/75mm 'Superdome' mid-range and 1”/25mm 'S-Spec' tweeter
- ATC 3-channel discrete 'amp-pack'
- Balanced instrumentation input combining high CMRR and very low noise
- 4th order active crossovers implemented with low-noise discrete circuitry
- MOSFET class A-B power stages delivering 200W bass, 100W mid and 50W high-frequency
- Power on/off trigger input and link output
- DC offset and thermal amp protection
Product Description:
ATC is delighted to introduce the EL50 Anniversary to audiophiles and music lovers seeking long-lasting high performance, design and engineering quality. It is the latest evolution of the legendary ATC 50 loudspeaker design, featuring ATCs discrete active tri-amp technology, renowned drive units and a new elliptical curved cabinet for optimal radiation from the mid and high-frequency drive units. Its industrial design draws from the EL150, released in 2006, the first ATC loudspeaker to employ an elliptical enclosure and designed by Billy Woodman. Leather detailing on the front face and beautiful hand-selected veneers further elevate the design.
Specifications:
| Bass driver | SB75-234SL 8Ω |
| Mid driver | SM75-150S 16Ω |
| High Frequency Driver | SH25-76S 6Ω |
| Low Frequency Cut-off | 32Hz (-6dB anechoic) |
| High Frequency Cut-off | 25kHz (-6dB) |
| Matched Response | +/-0.5dB |
| Crossover Point | 380Hz & 3.5kHz |
| MaxSPL | 112dB (per pair, IEC Weighted Pink Noise, 1m, anechoic) |
| Sensitivity | -17.5dBu (85dBC @1m, pink noise, per speaker, anechoic) |
| Balanced Input | Rear panel mounted female XLR, pin 2 +ve |
| Input Impedance | 20kΩ |
| Input CMRR | >80dB (20Hz–10kHz) |
| Input Sensitivity | 2.2dBu/1V or 8.2dBu/2V (switched, ref. full output) |
| Crossover Filters | 4th Order Linkwitz Riley |
| Amplifier type | Grounded Source MOSFET, class A/B, convection cooled (fan-less) |
| Output Power (Bass) | 200W (8Ω, continuous average, 0.1% THD) |
| Output Power (Mid) | 100W (16Ω, continuous average, 0.1% THD) |
| Output Power (HF) | 50W (8Ω, continuous average, 0.1% THD) |
| THD+N | 0.0015% / -96dB (1kHz, 1dB below rated power, 90kHz BW) |
| Frequency Response | 8Hz–190kHz |
| Limiter | FET momentary gain reduction, all channels |
| Electronic amp protection | Amplifier d.c. offset and over-temperature (rear panel LED indicated) |
| Mains Input | 220–230V / 110–115V factory set (see panel markings) |
| Power Trigger Input/Link | 2 x rear panel mounted, Switchcraft L712RA |
| Power Consumption | Idle 77W / 105VA; 1/8 Power 240W / 315VA; Full Power 600W / 730VA |
| Heat Output | Idle 77W / 263BTU; 1/8 Power 184W / 628BTU; Full Power 250W / 853BTU |
| Net Weight | 63kg / 139lbs |
| Dimensions | HxWxD 1421 x 459 x 352mm (55 15/16” x 18 1/16” x 13 7/8”) |
